Robot
Type:M-20iA
Robot Axes: 6 axes
Extemal Axes: 3 axes
Working Radius: 1850mm
Arm Load: 20Kg
Welding Power Source: PowerWave 455M
Rated Current: 450A
Rotation Arm
X-axis: 1500mm
Y-axis: 6000mm
Repeatability: ±0.1mm
Positioner
Tilt Angle: ±90°
Rotation Angle: ±360°
Repeataability: ±0.1mm@￠2000mm
Max.Tool Length: 2500mm
Max.Swing Diameter: 1500mm
Laod Capacity: 10T
Design based on the components drawing and customer requirementsArc Welding,Smartac,Arc Sensor
